T Shape Handle Flanged Base Wood Working Vertical Handle Toggle Clamp GH-101-AT
Manual Quick Release Vertical Hold Down Toggle Clamp Destaco GH-101-AT
Features:
Quick release, small holding capacity
Application: Welding, machining, checking fixture, assembly fixture, woodholding, metal holding.
| Weight (g) | Holding Capacity (kg) | Bar Opens (º) | Handle Opens (º) | Spindle Supplied |
| 59 | 56 | 99 | 55 | GH-FC-10138 |
Automobile Industry
1. Welding of various vehicle frames and accessories (small sheet metal parts) is used as positioning bolts and fixtures for welding jigs.
Main application models: 702-C,702-D,702-K,101-J,10247,12265,304-E,304-H,303-E etc.
2. Welding inspection of various vehicle frames and accessories (small sheet metal parts) is used as positioning bolts and fixtures for inspecting jigs. Main application models: 12135,12137,304-C,302-F etc.
3. Stamping of all kinds of vehicle frames, accessories (small sheet metal parts) and sheet metal door panel parts is used as positioning bolts and fixtures for stamping parts inspecting jigs. Main application models: 101-AT,12130,12135,11412,302-F,36020 etc.
4. Welding and welding inspection of various door panels are used as positioning bolts and fixtures for welding and testing molds.
Main application models: 702-C,702-D,101-E,10247,12130,12135,12137,304-E etc.
5. Welding of various automobile roof and side windows is used as fixtures for welding fittings. Main application models: 11412,203-F,21502-B.
Motorcycle Industry
1. Welding of car frames is used as positioning bolts and fixtures for welding molds.
Main application models: 101-AT,12265,11412,11421,101-B,12205,10247,22175,25382,36020,304-E,304-H,303-E,36060,702-C,30509 etc.
2. Steering column: welding of front and rear forks and guard frames is used as positioning bolts and fixtures for welding jigs.
Main application models: 11421,11412,22175,36020,302-F,303-E etc.
3. The production of engine cylinder heads and cylinder blocks is used as fixtures for drilling machines.
Main application models: 25383,25382,12265-A,12132-A etc.
4. Carburetors, mufflers and wire harnesses are all used in the same way as in the "automobile industry."
Note: Manual toggle clamps can be used for all products or parts that are similar to the above three points regarding the manufacture of materials and production methods and have the characteristics of continuous mass production.
| Q'TY PCS | 1-100 | 101-500 | 501-1000 | 1001-2000 | 2001-5000 | 5000+ |
| EST.DAYS | 1 | 3 | 7 | 15 | 25 | 35 |
| Brand | JOINTECH |
| Model | 101-AIT / 101-AT / 101-ATSS |
| Bar Type | U Bar T Handle |
| Base Type | Flanged or straight |
| Clamping Type | Vertical |
| Operation Type | Hold Down Quick Release |
| Holding Force (LBS) | 100 |
| Spindle Standard | mm/inch |
| Material | Carbon Steel; SUS#201; SUS#304; SUS#316; |
| Surface Treatment | Zinc Plated; Tumbled; Polished;Black Oxide; |
| Finish | Silver; Natural; Red / Blue / Black / Orange Dipped Grip; |
| Design | OEM & ODM |
| Price Term | Ex-works; FOB Shenzhen; CIF; CFR; DDU; DDP; DA; DP; |
| Sample Request | F.O.C. / $3USD |
| Stock Status: (PCS) | 100 |
| Package Method | PE Bag; Inner and Master Carton; Each Master Carton is Less than 50lbs; |
| Pallet | Wooden / Fumigation / Plywood / Plastic / Aluminum Alloy; |
| Shipment Method | Sea / Train / Truck / UPS / DHL / FEDEX / TNT / EMS |
